Powerful computing performance and exceptional scalability
Supports 2 AMD EPYC Turin 9005 series processors, compatible with Genoa 9004 series processors, with a maximum TDP of 500W. Supports up to 24 DDR5 memory slots with frequencies of 4800/6400MHz and a 75% increase in memory bandwidth. Equipped with 2 PCIe 3.0 M.2 NVMe SSDs (2280). CPU-GPU switch expansion mode supports 600W dual-width GPU cards. Supports SATA/SAS/NVMe tri-mode hard drive configurations to meet high-speed transmission and data storage needs.
New Architecture, Extreme Performance
Supports 1 or 2 AMD EPYC Turin series processors, compatible with 1 or 2 AMD EPYC Genoa series processors. Supports 24 DDR5 6000/4800MT/s ECC memory, with a 75% increase in memory bandwidth. Offers GPU-CPU direct connection or Switch expansion configurations for maximum multi-GPU compute power.
Flexible Topology, Key Applications
CPU-GPU Switch expansion supports up to 10 dual-width GPU cards running at high speeds and stability. CPU-Switch interconnect supports PCIe 5.0 x32, enabling high-bandwidth communication.
Rich Ecosystem, Stable and Reliable
| Product Specifications | |
|---|---|
|
System Model |
GAG6460A5-B12-G4
|
|
Processor |
Supports 1 or 2 AMD EPYC Turin series processors, compatible with AMD EPYC Genoa series processors |
|
GPU Card |
Supports up to 8 dual-width GPU cards
|
|
Memory |
24 DDR5 memory slots, supporting DDR5 4800/6400MHz memory |
|
Storage Controller |
2 PCIe3.0 M.2(2280/22110） |
|
Storage |
Supports 12 3.5″ /2.5" SAS/SATA/NVMe hot-swappable hard drives |
|
I/O Ports |
Front: 2 USB 3.0, 1 Power Button, 1 Reset Button, 1 Hard Drive Indicator, 1 System Fault Indicator, 2 Network Indicators
Rear: 1 VGA, 2 USB 3.0, 1 Management Port, 2 RJ45 Network Ports, 1 Serial Port
|
|
PCIe Expansion |
20 PCIe5.0 MCIO(x8)
Supports expansion of 8 x PCIe 5.0 x16 dual-width full-height full-length slots and 5 x PCIe 5.0 x16 single-width full-height full-length slots |
|
Power Supply |
Supports 2000W/2200W/2700W CRPS N+1 redundant power supply (configured based on actual power requirements) |
|
Fan |
Standard 12 x 6056 hot-swappable N+1 redundant fans |
|
Management |
1 dedicated RJ45 management network port |
|
Security |
Supports TPM 2.0 module, chassis intrusion alarm, and BMC/BIOS redundancy |
|
Operating System |
Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, VMware ESXi, etc. |
|
Server Size |
850 x 444 x 176.5 mm (D * W * H) |
